Introduction

• No. S2012
• Product Name S2012
• Description
  . Zinc alloy die cast housing and cylinder.
  . Bright nickel plated standard.
  . 4 disc tumbler mechanism.
  . Brass keys, nickel plated.
  . Spring loaded for momentary contact.
  . Golden plated contacts and terminals.
  . Hex nut or speed clip mounted.


  SPECIFICATION
  . Contact Rating: 4A 125VAC, 2A 250VAC. 4A 28VDC
  . Contact Resistance: 50Milli-Ohms Max.
  . Insulation Resistance: 500 Meg-Ohms Min. (500VDC)
  . Dielectric Strength: 1000 VAC -1 Minute.
